DoLast Do311 H-Beam Lifting Beam, rigid, Lifting Capacity: 1000 kg, Length: 2000 mm, Width: 1000 mm

Do311 – Stability in an H
Sometimes, length alone isn’t enough: when your load is not only long but also wide, a standard beam lifting solution quickly reaches its limits. That’s exactly where the Do311 H-Beam Lifting Beam shows its true strength. With a working length of 2,000 mm and a width of 1,000 mm, it provides even load distribution in both directions – ideal for bulky and large-area loads.

Engineered for Symmetrical Lifting Operations
Need safe lifting of control cabinet elements, pallet frames, containers, or machine components? The Do311 is designed precisely for such applications. Its four robust eye hooks (Type OS-DD) at the ends ensure twist-resistant attachment. The rigid H-profile delivers maximum dimensional stability and minimizes unwanted load movement – a clear advantage when precision and security are critical.

Technical Specifications at a Glance

• Model: Do311

• Design: H-Beam Lifting Beam (rigid)

• Lifting Capacity: 1,000 kg

• Working Length: 2,000 mm

• Working Width: 1,000 mm

• Lifting Points: 4x Eye Hooks OS-DD

• Material: Steel, painted yellow

• Application: Symmetrical lifting of large-surface loads

• Standards: DIN EN 13155

When It Gets Wide – Choose the Do311
The Do311 brings structure and safety to your lifting operations – whether you're handling workpiece carriers, structural frames, or large assemblies. With its four clearly defined lifting points and statically optimized design, you're always on the safe side.

Need more flexibility?
Custom dimensions are always possible – just get in touch!
